Sony ST-EX880 - 3 Disassembly

– 5 –
MAIN BOARD
Note: Follow the disassembly procedure in the numerical order given.
SECTION 3
DISASSEMBLY
3 case
0 three screws
(BVTP3
× 10)
1 two screws
(case3 TP2)
4 flat type wire (19 core)
(CN102)
!¡ claw
7 two claws
6 two screws
(BVTT3
× 6)
7 claw
8 front panel ass’y
5 connector
(CN104)
!¡ claw
!™ MAIN board
9 two screws
(BVTP3
× 8)
1 two screws
(case3 TP2)
2 screw
(BVTT3
× 6)
