Sony ST-S3 Service Manual

28
ST-S3
SECTION 7
ELECTRICAL PARTS LIST
DSP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4476-212-A DSP BOARD, COMPLETE
********************
< CAPACITOR >
C601 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C602 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C609 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C610 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C611 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C613 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C614 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C615 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C616 1-126-934-11 ELECT 220uF 20% 10V
C617 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C618 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C619 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C620 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C621 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C623 1-126-934-11 ELECT 220uF 20% 10V
C624 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C625 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C626 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C627 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C628 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C629 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C630 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C631 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C633 1-126-934-11 ELECT 220uF 20% 10V
C634 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C635 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C636 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C637 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C638 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C639 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C640 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C642 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
C643 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C644 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C645 1-126-934-11 ELECT 220uF 20% 10V
C646 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C647 1-126-934-11 ELECT 220uF 20% 10V
C658 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C659 1-126-934-11 ELECT 220uF 20% 10V
C660 1-126-934-11 ELECT 220uF 20% 10V
C661 1-126-934-11 ELECT 220uF 20% 10V
C662 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C664 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C665 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C666 1-126-934-11 ELECT 220uF 20% 10V
C667 1-126-964-11 ELECT 10uF 20% 50V
C668 1-126-964-11 ELECT 10uF 20% 50V
C669 1-126-964-11 ELECT 10uF 20% 50V
C670 1-126-964-11 ELECT 10uF 20% 50V
C671 1-126-964-11 ELECT 10uF 20% 50V
C672 1-126-964-11 ELECT 10uF 20% 50V
C673 1-126-964-11 ELECT 10uF 20% 50V
C674 1-126-964-11 ELECT 10uF 20% 50V
C678 1-126-964-11 ELECT 10uF 20% 50V
C679 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C680 1-126-964-11 ELECT 10uF 20% 50V
C684 1-126-964-11 ELECT 10uF 20% 50V
C685 1-126-964-11 ELECT 10uF 20% 50V
C686 1-126-933-11 ELECT 100uF 20% 16V
C687 1-126-933-11 ELECT 100uF 20% 16V
C689 1-126-933-11 ELECT 100uF 20% 16V
C690 1-126-934-11 ELECT 220uF 20% 10V
C691 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C692 1-136-165-00 MYLAR 0.1uF 5% 50V
C693 1-136-165-00 MYLAR 0.1uF 5% 50V
C694 1-136-165-00 MYLAR 0.1uF 5% 50V
C695 1-136-165-00 MYLAR 0.1uF 5% 50V
C699 1-126-964-11 ELECT 10uF 20% 50V
C700 1-126-964-11 ELECT 10uF 20% 50V
C704 1-126-961-11 ELECT 2.2uF 20% 50V
C705 1-126-964-11 ELECT 10uF 20% 50V
C706 1-126-964-11 ELECT 10uF 20% 50V
C707 1-126-964-11 ELECT 10uF 20% 50V
C708 1-126-964-11 ELECT 10uF 20% 50V
C709 1-126-964-11 ELECT 10uF 20% 50V
