6
ST-S3
3-3. FRONT PANEL SECTION
2
three screws
(BVTP3
×
8)
3
claw
3
two claws
1
wire (flat type) (19 core)
(CN502)
3
two claws
4
front panel section
Note: Follow the disassembly procedure in the numerical order given.
3-2. COVER
2
two screws
(case 3 TP2)
3
cover
1
screw
(+BVTT3
×
6 (S))
2
two screws
(case 3 TP2
)
