Sony ST-S3 Service Manual

8
ST-S3
4 screw
(BVTP3
× 8)
2 five connectors
(CN510, 5031, 5032, 5041, 5042)
        
1 wire (flat type) (23 core)
(CN508)
1 wire (flat type) (21 core)
(CN509)
6 MAIN board
1 wire (flat type) (19 core)
(CN502)
5 PC board holder
2 connector
(CN601)
3 three screws
(BVTP3 × 8)
4 two screws
(BVTP3 × 8)
1 wire (flat type) (23 core)
(CN603)
4 three screws
(BVTP3 × 8)
3 three screws
(BVTP3
× 8)
6 DSP board
1 wire (flat type) (21 core)
(CN602)
2 connector
(CN601)
5 PC board holde
r
3-7. DSP BOARD
3-6. MAIN BOARD
