STR-KS1000
6
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE (SL06)
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
1
two screws
(BVTP3
×
8)
2
two tapping screw
s
2
two tapping screws
3
case (SL06)
3-2. CASE (SL06)
(Page 6)
SET
3-3. FRONT PANEL ASSY
(Page 7)
3-4. HDMI BOARD
(Page 7)
3-5. MAIN BOARD
(Page 8)
