STR-KS1000
8
3-5. MAIN BOARD
7
screw
(BVTP3
×
12)
9
heat sink (AMP)
8
two screws
(BVTP3
×
8)
0
three screws
(BVTP3
×
6)
qa
six screws
(BVTP3
×
6)
qs
MAIN board
1
two connector
(CNP500, CNP510)
2
wire (flat type) (15 core) (AEP, UK)
wire (flat type) (11 core) (Singapore,
Malaysia, Chilean, Peruvian and
Argentina models) (CNS195)
5
connector (CNP196)
3
wire (flat type) (13 core)
(CNS198)
4
wire (flat type) (17 core)
(CNS193)
6
connector
(CN901)
qd
two radiation sheets (AMP)
Ver. 1.2
