STR-KS1000
7
3-3. FRONT PANEL ASSY
3-4. HDMI BOARD
(Except Chilean, Peruvian and Argentina models)
3
screw
(BVTP3
×
6)
5
four screws
(BVTP3
×
6)
7
front panel assy
4
two harnesses
6
four claws
1
wire (flat type) (17 core)
(CNS193)
2
connector
(CNP196)
1
connector
(CN5004)
3
HDMI boar
d
