51
STR-KS1100
SECTION 6
ELECTRICAL PARTS LIST
DISPLAY
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DCAC BOARD
***********
< CAPACITOR >
C2001 1-124-589-11 ELECT 47uF 20% 16V
C2002 1-124-589-11 ELECT 47uF 20% 16V
C2003 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2004 1-126-160-11 ELECT 1uF 20% 50V
C2005 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C2006 1-100-436-11 CERAMIC CHIP 0.033uF 10% 25V
C2007 1-126-160-11 ELECT 1uF 20% 50V
C2008 1-100-436-11 CERAMIC CHIP 0.033uF 10% 25V
C2009 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C2010 1-126-160-11 ELECT 1uF 20% 50V
C2011 1-124-465-00 ELECT 0.47uF 20% 50V
C2015 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2016 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2017 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< DIODE >
D863 8-719-404-50 DIODE MA111-TX
D864 8-719-404-50 DIODE MA111-TX
< IC >
IC2000 8-759-710-97 IC NJM4565M-D
< JACK >
J2000 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC)
< RESISTOR >
R2001 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2002 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2004 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2005 1-216-857-11 METAL CHIP 1M 5% 1/10W
R2006 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2007 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2008 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2009 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2010 1-216-854-11 METAL CHIP 560K 5% 1/10W
R2011 1-216-836-11 METAL CHIP 18K 5% 1/10W
R2012 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2013 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2014 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2015 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
************************************************************
A-1227-752-A DISPLAY BOARD, COMPLETE
************************
4-246-476-01 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C700 1-126-795-11 ELECT 10uF 20% 50V
C701 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C702 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C703 1-126-795-11 ELECT 10uF 20% 50V
C704 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C705 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C706 1-126-795-11 ELECT 10uF 20% 50V
C707 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C708 1-126-795-11 ELECT 10uF 20% 50V
C709 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C711 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C750 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C751 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C752 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C753 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C754 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C755 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C756 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C757 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C758 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C759 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C760 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C761 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C762 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C763 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C764 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C768 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
CN700 1-568-672-11 CONNECTOR, BOARD TO BOARD 12P
CNS701 1-784-780-11 CONNECTOR, FFC 19P
DCAC
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board.
