STR-KS1100
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1227-749-A IO BOARD, COMPLETE
******************
< CAPACITOR >
C1441 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1601 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1602 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1603 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1604 1-126-933-11 ELECT 100uF 20% 16V
C1605 1-126-964-11 ELECT 10uF 20% 50V
C1606 1-126-933-11 ELECT 100uF 20% 16V
C1607 1-126-933-11 ELECT 100uF 20% 16V
C1608 1-126-964-11 ELECT 10uF 20% 50V
C1651 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1652 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1655 1-126-964-11 ELECT 10uF 20% 50V
C1700 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1701 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1702 1-126-964-11 ELECT 10uF 20% 50V
C1703 1-126-965-11 ELECT 22uF 20% 50V
C1704 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1706 1-126-916-11 ELECT 1000uF 20% 6.3V
C1707 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1708 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1709 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1710 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1711 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1712 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1713 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1714 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1715 1-126-964-11 ELECT 10uF 20% 50V
C1716 1-126-964-11 ELECT 10uF 20% 50V
C1717 1-126-964-11 ELECT 10uF 20% 50V
C1718 1-126-964-11 ELECT 10uF 20% 50V
C1719 1-126-964-11 ELECT 10uF 20% 50V
C1720 1-126-964-11 ELECT 10uF 20% 50V
C1721 1-126-933-11 ELECT 100uF 20% 16V
C1722 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1723 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1724 1-126-933-11 ELECT 100uF 20% 16V
C1725 1-126-964-11 ELECT 10uF 20% 50V
C1726 1-126-933-11 ELECT 100uF 20% 16V
C1727 1-126-964-11 ELECT 10uF 20% 50V
C1731 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1732 1-126-933-11 ELECT 100uF 20% 16V
C1735 1-126-964-11 ELECT 10uF 20% 50V
C1736 1-126-964-11 ELECT 10uF 20% 50V
C1737 1-126-964-11 ELECT 10uF 20% 50V
C1738 1-126-964-11 ELECT 10uF 20% 50V
C1739 1-126-964-11 ELECT 10uF 20% 50V
C1744 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1747 1-126-964-11 ELECT 10uF 20% 50V
C1748 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1749 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN1700 1-817-615-21 CONNECTOR BOARD TO BOARD 18P(DMPORT)
CNS197 1-568-838-11 CONNECTOR, FFC 21P
< DIODE >
D1700 8-719-404-50 DIODE MA111-TX
< FERRITE BEAD >
FB1303 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1304 1-469-670-21 FERRITE, EMI (SMD) (2012)
< IC >
IC1600 8-759-710-97 IC NJM4565M-D
IC1603 8-759-710-97 IC NJM4565M-D
IC1700 6-600-466-01 IC TORX147L (SONY) (DIGITAL OPT IN SAT)
IC1701 6-600-466-01 IC TORX147L (SONY)
(DIGITAL OPT IN VIDEO 2/BD)
IC1702 8-759-242-70 IC TC7WU04F
IC1710 6-703-518-01 IC BD3842FS-FD2
< JACK >
J1700 1-793-446-21 JACK, PIN 1P (DIGITAL COAX IN DVD)
J1710 1-784-920-11 JACK, PIN 6P (SA-CD/CD AUDIO IN,
TV AUDIO IN, VIDEO 1 AUDIO IN)
< COIL >
L1603 1-469-525-11 INDUCTOR 10uH
L1606 1-469-525-11 INDUCTOR 10uH
< RESISTOR >
R1601 1-216-833-11 METAL CHIP 10K 5% 1/10W
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board.
