STR-KS1100
6
2-3. FRONT PANEL ASSY
2-4. HDMI BOARD
3
screw
(BVTP3
×
8)
5
two screws
(BVTP3
×
8)
6
four screws
(BVTP3
×
8)
8
front panel assy
4
two harnesses
7
four claws
1
wire (flat type) (17 core)
(CNS193)
2
connector
(CNP196)
1
connector
(CN5004)
3
HDMI board
2
three screws
(BVTT3
×
6)
