Sony VPL-HS50 User Manual

60 Ceiling Installation
Front view
Side view
125 (5)
250 (9
7
/
8
)
66 (2
5
/
8
)
75 (3)
Ceiling
The bottom
surface of the
mount bracket
Center of the
supporting pole
Center of the lens
Distance between the ceiling and the surface of the mount bracket
Using adjustment pipe (b): 150/175/200 mm (6 / 7 / 7
7
/8 inches)
Using adjustment pipe (c): 250/275/300 mm (9
7
/8 / 10
7
/8 / 11
7
/8 inches)
224.5
(8
7
/
8
)
216.5
(8
5
/
8
)
152.5
(6
1
/
8
)
135.5
(5
3
/
8
)
13
(
17
/
32
)
Center of the lens
Front of the cabinet
