Sony XM-504Z Service Manual

13
XM-504Z
SECTION 5
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
A-3283-674-A MAIN BOARD, COMPLETE
*********************
3-266-086-01 COVER (LED)
3-912-431-01 SCREW (+–P)
7-682-648-09 SCREW +PS 3X8
7-682-948-01 SCREW +PSW 3X8
7-685-146-14 SCREW +P 3X8 TYPE2 NON-SLIT
< CAPACITOR >
C101 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C102 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C105 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C106 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C107 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C110 1-126-933-11 ELECT 100uF 20% 16V
C111 1-126-963-11 ELECT 4.7uF 20% 50V
C112 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C151 1-126-947-11 ELECT 47uF 20% 25V
C152 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C153 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C154 1-126-960-11 ELECT 1uF 20% 50V
C155 1-104-760-11 MYLAR 0.047uF 10% 50V
C201 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C202 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C205 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C206 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C207 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C208 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C209 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C210 1-126-933-11 ELECT 100uF 20% 16V
C211 1-126-963-11 ELECT 4.7uF 20% 50V
C212 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C251 1-126-947-11 ELECT 47uF 20% 25V
C252 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C253 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C254 1-126-960-11 ELECT 1uF 20% 50V
C255 1-104-760-11 MYLAR 0.047uF 10% 50V
C301 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C302 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C305 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C306 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C307 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C308 1-126-960-11 ELECT 1uF 20% 50V
C309 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C310 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C311 1-126-933-11 ELECT 100uF 20% 16V
C312 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C351 1-126-947-11 ELECT 47uF 20% 25V
C352 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C353 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C354 1-126-960-11 ELECT 1uF 20% 50V
C355 1-104-760-11 MYLAR 0.047uF 10% 50V
C401 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C402 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C405 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C406 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C407 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C408 1-126-960-11 ELECT 1uF 20% 50V
C409 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C410 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C411 1-126-933-11 ELECT 100uF 20% 16V
C412 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C451 1-126-947-11 ELECT 47uF 20% 25V
C452 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C453 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C454 1-126-960-11 ELECT 1uF 20% 50V
C455 1-104-760-11 MYLAR 0.047uF 10% 50V
C801 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C802 1-126-934-11 ELECT 220uF 20% 16V
C803 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C804 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C805 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C808 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C809 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C810 1-126-965-11 ELECT 22uF 20% 50V
C811 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C812 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C813 1-104-655-11 ELECT 470uF 20% 6.3V
C814 1-104-655-11 ELECT 470uF 20% 6.3V
C815 1-126-933-11 ELECT 100uF 20% 16V
C817 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C818 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C819 1-165-949-11 ELECT 1500uF 35V
C820 1-165-949-11 ELECT 1500uF 35V
C821 1-165-949-11 ELECT 1500uF 35V
C822 1-165-949-11 ELECT 1500uF 35V
C823 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
MAIN
•Abbreviation
CND : Canadian model
