ZS-S50CP
11
3-9. OPTICAL PICK-UP BLOCK (KSM-213CCP)
1
Remove four solders.
5
Remove four solders.
6
detection switch (limit)
(S201)
2
flexible flat cable (16 core)
(CN301)
7
CD board
4
optical pick-up block
(KSM-213CCP)
3
screw
(BVTT2
×
6)
