48
ZS-S50CP
302
not supplied
(MO
TOR board)
not supplied
not supplied
CD bloc
k
305
305
303
305
303
305
304
306
301
303
304
7-7.
LO
ADING MECHANISM SECTION
Ref. No.
Part No.
Description
Remark
Ref. No.
Part No.
Description
Remark
301
A-1242-967-A
LOADING (BK) ASSY
302
3-080-478-01
BEL
T
303
4-985-672-01
SCREW (+PTPWH M2.6), FLOA
TING
304
4-227-045-41
SPRING (INSULA
TOR)
305
4-229-005-41
INSULA
TOR
306
3-208-653-01
SP
ACER (CD MECHANICAL)
47
49
