Sony ZS-SN10 User Manual

10
Listening to the radio
Connect the supplied AC power cord (see page 26).
1 Press RADIO•BAND•AUTO
PRESET repeatedly until the band
you want appears in the display
(direct power-on).
2 Hold down TUNE + or – until the
frequency digits begin to change in
the display.
The player automatically scans the
radio frequencies and stops when it
finds a clear station.
If you can’t tune in a station, press
TUNE + or – repeatedly to change
the frequency step by step.
1 2
Display
Indicates an FM
stereo broadcast

Sony ZS-SN10 Specifications

General

Bundled software	SONICSTAGE Software 2.0
Audio system	Bass Reflex
Line-in	Yes
I/O ports	Headphone Output
Device type	Personal CD player
Product color	Silver
Preset stations quantity	40
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Battery type	6 X LR14 (not supplied)
Dimensions (WxDxH)	500 x 230 x 145 mm
Loudspeaker diameter	100 mm
Power requirements	AC 230 V
Number of batteries supported	6

Weight and Dimensions

Weight	3800 g
