Sony ZS-SN10 User Manual

33
General
Speaker
Full range: 10 cm (4 in.) dia., 3.2 Ω, cone type (2)
Input
LINE IN jack (stereo minijack):
Minimum input level 330 mV
Outputs
Headphones jack (stereo minijack):
For 16 - 64 Ω impedance headphones
Power output
2.3 W + 2.3 W (at 3.2 Ω, 10 % harmonic
distortion)
Power requirements
For player:
120 V AC, 60 Hz
9 V DC, 6 size D (R20) batteries
For remote control:
3 V DC, 2 size AAA (R03) batteries
Power consumption
16 W
Battery life
For player:
CD playback
Sony R20P: approx. 2 h
Sony alkaline LR20: approx. 8 h
Radio reception
Sony R20P: approx. 10 h
Sony alkaline LR20: approx. 25 h
Dimensions
Approx. 500 × 145 × 230 mm (w/h/d)
(19
3
/4 × 5
3
/4 × 9
1
/8 inches) (incl. projecting parts)
Mass
Approx. 3.8 kg (8 lb. 6 oz) (incl. batteries)
Supplied accessories
AC power cord (1)
Remote control (1)
CD-ROM (SonicStage) (1)
SonicStage Installation/Operating Guide (1)
US and foreign patents licensed from Dolby Laboratories.
Design and specifications are subject to change without
notice.
Optional accessories
Sony MDR headphones series

Sony ZS-SN10 Specifications

General

Bundled software	SONICSTAGE Software 2.0
Audio system	Bass Reflex
Line-in	Yes
I/O ports	Headphone Output
Device type	Personal CD player
Product color	Silver
Preset stations quantity	40
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Battery type	6 X LR14 (not supplied)
Dimensions (WxDxH)	500 x 230 x 145 mm
Loudspeaker diameter	100 mm
Power requirements	AC 230 V
Number of batteries supported	6

Weight and Dimensions

Weight	3800 g
