– 104 –
APPENDIX
A-1. General Specifications
(1) Printing method Direct line thermal printing
(2) Print speed Max. 800 dots/sec. (100 mm/sec.)
(3) Dot density 203 dpi: 8 dots/mm (0.125 mm/dot)
(4) Printing width Max. 72 mm
(5) Number of print columns
Max.48 (12 × 24 dots)
Max.64 (9 × 24 dots: ESC/POS mode)
(6) Roll paper Refer to chapter 2 for details on the recommended roll
paper.
Paper width:79.5±0.5 mm or 57.5±0.5 mm (option)
Roll diameter: ø90 mm or less
(7) Overall dimension 142 (W) × 199 (D) × 132 (H) mm
(8) Weight Approx. 1.4 kg
(9) Noise Approx. 53 dB (Auto cutter model)/49 dB (Tear bar model)
Appendix A: Specifications
199 mm
132 mm142 mm
To Next Page
