Edition Manual Chapter Page
2008-05-19 Workshop Manual, Stiga Villa/Ready 2 Chassis and Body 1
2 Chassis and body
Contents in this chapter
General
To facilitate the driving, handling of work equipment and to make it comfortable for the
driver, the machines are equipped with a various number of aid equipments. These
equipments are mainly the same for all the machines covered by this manual, but in some
cases configurated in different ways. Where divergences occour between the machines,
particular instructions are given for each particular equipment.
This chapter gives a brief description of the equipments and describes their repair and
replacements.
2.2 Lubrication chassis .................... 8
2.2.1 Steering pivot pins
and beam pivot........................ 8
2.2.2 Control wires............................ 8
2.2.3 Tensioning arms ...................... 9
2.2.4 Steering chain.......................... 9
2.2.5 Bearings................................... 9
2.1 Lifting mechanism,
manual ..........................................2
2.1.1 General.....................................2
2.1.2 Description................................2
2.1.3 Dismantling...............................2
2.1.4 Repair of lifting lock ..................6
2.1.5 Assembly ..................................6
