Edition Manual Chapter Page
2008-05-19 Workshop Manual, Stiga Villa/Ready 3 Steering 1
3 Steering
Contents in this chapter
General
The Villa and Ready machines are equipped with a mechanical steering system, working
with wires or chains, depending on the model.
This chapter contains a brief description of the function and describes repair, replacements
and adjustments of stressed parts of the steering system.
This chapter is valid for the actual machines where the actual system occur.
3.2 Bearings, steering shaft........... 6
3.2.1 Replacement of sliding
bearings................................. 6
3.1 Steering wire/chain....................2
3.1.1 Description .............................2
3.1.2 Dismantling.............................2
3.1.3 Assembly................................3
3.1.4 Steering pulleys......................5
3.1.5 Adjusting the steering wire .....5
