No. Part Name Part No. Application Rem.
1 Locking strip for piston 4221 893 5900 Blocking crankshaft 1)
2 Socket 0812 540 1112 Releasing clutch drum
3 Wrench 4130 890 3600 Removing and installing
clutch
4 Puller 5910 890 4400 Removing oil seals 2)
5 - Jaws (No. 3.1 + 4) 0000 893 3706
6 - Jaws (No. 1 + 2) 0000 893 3700 Clamping engine pan and
crankcase
7 - Screw bush 1108 893 4500
8 Carburetor and 1106 850 2905 Testing carburetor and
crankcase tester crankcase for leaks
9 Vacuum pump 0000 850 3501 Testing crankcase for leaks
10 - Nipple 0000 855 9200
11 - Fuel hose 1110 141 8600
12 Sealing plate 0000 855 8106 Sealing exhaust port for
leakage test
13 Test flange 1128 850 4200 Leakage test
14 Installing sleeve 1129 893 4600 Protecting oil seal
(starter side)
15 Press sleeve 1114 893 4601 Installing oil seal
(starter side)
16 Press sleeve 1120 893 2400 Installing oil seal
(clutch side)
17 Setting gauge 1127 890 6400 Setting air gap between ignition 3)
module and flywheel
18 Screwdriver 5910 890 2420 Unscrewing carburetor nuts
Q-SW8x200
19 Crimping tool 5910 890 8210 Attaching connectors to
electrical wires
20 Torque wrench 5910 890 0301 0.5 - 18 Nm 4)
(0.4 - 13.5 lbf.ft)
5910 890 0302 5)
21 Torque wrench 5910 890 0311 6 - 80 Nm 4)
(4.4 - 60 lbf.ft)
5910 890 0312 5)
22 Spline screw socket T27x125 0812 542 2104 IS screws
23 Screwdriver 5910 890 2400 All IS screws 6)
Q-T27x150
11. Special Servicing Tools and Aids
11.1 Special Servicing Tools
34 FS 45
