Page 16 Technical Information 40.2010
TI_40_2010_13_01_02.fm
7. Service accessories
7.1 New special tools
7.2 Existing special tools
The existing special tools are listed in the Service
Manual for STIHL FS 240 C, FS 260 C, FS 360 C,
FS 410 C, FS 460 C.
Designation Part number Use
1 Setting gauge 0000 890 6400 Setting the air gap between ignition module and
flywheel
2 Press sleeve 4147 893 2400 Press in oil seal
3 Flange 5910 850 4201 Leak testing
4 Puller 5910 890 4408 Removing the drive pinion of the gearbox
5 Sleeve 5910 893 1709 Mounting the hookless snap ring
6 Ring 5910 893 7005 Place on the clutch housing to protect the guide
sleeves
7 Puller 5910 890 4503 Removing the flywheel and the starter-side half of the
crankcase
2
3
1
4
5
6
7
317TI028 KN
