English 22 Specifications
22.1 STIHL MSE 141 C
– Mains voltage: 120 V
– Rated current: 11.6 A
– Frequency: 60 Hz
– Rated power: 1400 W
– Motor is not waterproof
– Insulation: Class II (Double Insulation)
– Weight without guide bar and saw chain: 8.8 lbs. (4.0 kg)
– Maximum oil tank volume: 7.3 oz. (0.215 l)
22.2 Extension Cords
Use an extension cord that is at least 35 ft. (10 m) long and
meets the specifications below.
– Types: SJW or SJTW, round jacketed cords
– W marking on cable jacket must indicate that it is suitable
for outdoor use
Minimum wire size for extension cords for 120 Volt
appliances, using not more than 12 A:
– Cord length 35 ft. (10 m): AWG 16
– Cord length 50 ft. (15 m): AWG 14
– Cord length 100 ft. (30 m): AWG 12
– Cord length 150 ft. (46 m): AWG 10
Minimum wire size for extension cords for 120 Volt
appliances, using not more than 15 A:
– Cord length 35 ft. (10 m): AWG 16
– Cord length 50 ft. (15 m): AWG 14
– Cord length 100 ft. (30 m): not recommended
– Cord length 150 ft. (46 m): not recommended
22.3 Chain Sprockets
– 7-tooth for 3/8" PICCO
– 8-tooth for 1/4" PICCO
22.4 Minimum Groove Depth of Guide Bars
The minimum groove depth of a guide bar depends on the
pitch of the guide bar.
– 1/4" PICCO: 0.157 in. (4 mm)
– 3/8" PICCO: 0.197 in. (5 mm)
22.5 Sharpening Angle of Saw Chains
– 61 PMM3 (Type 3610): 30°
– 71 PM3 (Type 3670): 30°
22.6 Depth Gauge Setting
The depth gauge setting of a saw chain depends on the pitch
of the saw chain.
– 1/4" P: 0.018 in. (0.45 mm)
– 3/8" P: 0.026 in. (0.65 mm)
22.7 Symbols on the Chain Saw
22 Specifications
Symbol Explanation
VVolt
Hz Hertz
A Ampere
Engage and disengage the chain brake.
Chain Brake is disengaged.
Chain Brake is engaged.
