MSE 170 C, MSE 190 C, MSE 210 C, MSE 230 C
English
28
When the machine is not in use, store it
in such a way that it does not endanger
others.
Secure it against unauthorized use.
The overload cutout interrupts the power
supply to the saw in the case of
mechanical overload due to, e.g.
– excessive feed force
– "lugging down" the motor
– pinching the saw chain in the cut
If the overload cutout has interrupted the
power supply:
N Pull the guide bar out of the cut.
N If necessary, disengage the chain
brake – see "Chain Brake".
MSE 170 C, MSE 190 C, MSE 210 C
N Wait for the overload cutout to cool
down.
N Depress the reset button (1) as far
as stop – if the motor does not run
when you switch on, the overload
cutout has not yet cooled down
sufficiently – wait a while and then
depress the reset button again as
far as stop.
When the motor restarts:
N Run the motor off-load for about
15 seconds. This cools the motor
and helps prevent the overload
cutout from tripping again.
MSE 230 C
The MSE 230 C is equipped with an
electronic overload cutout to monitor
motor temperature and power
consumption.
N If the indicator lamp (1) stays on for
longer than 2 seconds in an
overload situation, the power supply
is interrupted and the saw is
switched off automatically – release
the trigger switch, then restart the
saw.
N If the saw then restarts at a reduced
RPM, it is overheated and switches
off automatically after about
10 seconds – release the trigger
switch, allow the saw to cool down
for about one minute, then restart. If
the saw again restarts at a reduced
RPM, it has not cooled down
sufficiently – allow it to cool down for
a long as necessary until it restarts
at normal RPM.
The indicator lamp glows only as long as
the trigger switch is operated.
Overload Cutout
1
9931BA006 KN
1
9931BA035 KN
