MSE 170 C, MSE 190 C, MSE 210 C, MSE 230 C
English
31
For periods of 3 months or longer
N Disconnect the plug from the wall
outlet.
N Remove the saw chain and guide
bar, clean them and spray with
corrosion inhibiting oil.
N Thoroughly clean the machine,
especially the cooling air inlets.
N If you use a biological chain and bar
lubricant, e.g. STIHL BioPlus,
completely fill the chain oil tank.
N Store the machine in a dry and
secure location – out of the reach of
children and other unauthorized
persons.
N Disconnect the plug from the wall
outlet.
N Remove the chain sprocket cover,
chain and guide bar.
Replace the chain sprocket
1 7-tooth sprocket (MSE 210 C,
MSE 230 C)
2 6-tooth sprocket with washer
(MSE 170 C, MSE 190 C)
– after using two saw chains or
sooner
– if the wear marks (a) on the
sprocket are deeper than 0.5 mm –
the life of the chain would otherwise
be reduced. Use reference gauge
(special accessory) to check the
depth of the wear marks.
It is best to use two saw chains in
rotation with one sprocket.
STIHL recommends the use of original
STIHL sprockets to ensure correct
operation of the chain brake.
MSE 170 C and MSE 190 C
N Ease the E-clip (1) off the shaft.
N Remove and inspect the washer (3)
– replace it if it shows signs of wear.
N Install the new chain sprocket in the
reverse sequence.
MSE 210 C and MSE 230 C
N Ease the E-clip (1) off the shaft.
N Remove and inspect the washer (2)
– replace it if it shows signs of wear.
N Remove the chain sprocket (3).
N Install the new chain sprocket in the
reverse sequence.
Storing the Machine Checking and Replacing the
Chain Sprocket
a
9931BA008 KN
a
1 2
9931BA016 KN
1
3
9931BA009 KN
1
2
3
