Stihl RE 120 User Manual

0458-620-0121-A
27
English 13 Transporting
► Pour antifreeze into a clean container.
► Insert water hose into container of antifreeze.
► Squeeze and hold spray gun trigger.
► Switch on pressure washer.
► Hold down spray gun trigger until an even jet of antifreeze
is delivered from the spray gun and point the spray gun
into the container.
► Press and release spray gun trigger several times.
► Switch off pressure washer and unplug mains plug from
the socket.
► Detach spray gun, high-pressure hose and water hose
and allow antifreeze to run into the container.
► Store and dispose of antifreeze in accordance with the
applicable regulations and in an environmentally
responsible manner.
13.1 Transporting the pressure washer
► Switch off pressure washer and unplug mains plug from
the socket.
► Empty the detergent bottle or secure it so that it cannot
topple over or fall and cannot move.
► If pulling the pressure washer along: Pull the pressure
washer by the handle (1).
► If carrying the pressure washer: Carry the pressure
washer by the handle (1) and carrying handle (2).
► If transporting the pressure washer in a vehicle, ensure
that the following conditions are fulfilled:
– The pressure washer is standing upright or lying on its
back.
– The pressure washer is secured with lashing straps,
belts or a net and cannot topple over or move.
– If the pressure washer cannot be protected from frost in
transport: Protect the pressure washer with antifreeze.
14.1 Storing the pressure washer
► Switch off pressure washer and unplug mains plug from
the socket.
► The pressure washer should be stored in such a way that
the following conditions are fulfilled:
– The pressure washer is out of the reach of children.
– The pressure washer is clean and dry.
– The pressure washer is in an enclosed room.
– The pressure washer is in a temperature range above
0°C.
– If the pressure washer cannot be protected from frost in
storage: Protect the pressure washer with antifreeze.
15.1 Cleaning the pressure washer and accessories
► Switch off pressure washer and unplug mains plug from
the socket.
► Clean the pressure washer, high-pressure hose, spray
gun and accessories with a damp cloth.
► Clean the connectors and couplings on the pressure
washer, high-pressure hose and spray gun with a damp
cloth.
13 Transporting
1
1
2
0000-GXX-4623-A0
14 Storing
15 Cleaning

Stihl RE 120 Specifications

General

Form factor	Upright
Hose length	8 m
Cable length	5 m
Power source	Electric
Product color	Black, Orange
Pump material	Aluminum
Detergent tank	-
Maximum flow rate	500 l/h
Minimum flow rate	400 l/h
Sound power level	81 dB
Vibration emission	3.8 m/s²
Working pressure (max)	140 bar
Working pressure (min)	125 bar
Maximum water temperature	40 °C
AC input voltage	230 V
Power consumption (typical)	- W

Weight and Dimensions

Weight	20000 g
