RE 143, RE 143 PLUS, RE 163, RE 163 PLUS
English
45
The following accessory parts must be
fitted before using the machine for the
first time.
Holder for spray attachment
N Slide the upper holder into the
mount on the handle and fasten it
with the screw
N Slide the lower holder into the
mount on the housing – until it
engages
Connector on water inlet
N Attach the connector (1) to the
water inlet (2) and tighten it by hand
Storage compartment for nozzles
N Open the flap – the rotary nozzle
and fan jet nozzle can be stored in
the holders
Holder for high-pressure hose RE 143,
RE 163
N Position the holder (1) for the high-
pressure hose on the bottom of the
handle and fasten it with the
screws (2)
Crank for hose reel RE 143 PLUS,
RE 163 PLUS
N Fit knob (1) onto crank (2).
N Engage crank (2) into the hose reel
support (3)
Storing accessories
The cleaning pin and other accessories
can be stored directly on the machine –
see "Main Parts".
Assembling the Unit
