Stihl RE 163 User Manual

RE 143, RE 143 PLUS, RE 163, RE 163 PLUS
English
62
1 Spray gun
2 Lever
3 Safety catch
4 Spring button
5 High-pressure hose
6 Spray lance
7 Rotary nozzle
8 High-pressure nozzle, adjustable
9 Handle
10 Upper holder for spray attachment
11 High-pressure hose connection
12 Hose reel
13 Crank for hose reel
14 Button for height adjustment of
handle
15 Machine switch
16 Detergent metering knob
17 Holder for power cord
18 Holder for special accessories, e.g.,
rotary washing brush
19 Storage compartment for nozzles
20 Pressure gauge
21 Lower holder for spray attachment
22 Water attachment
23 Pressure/quantity control knob
24 Carrying handle
25 Hose holder
26 Cleaning pin
27 Spray gun holder
28 Detergent tank
29 Flat hose cassette (included or
available as a special accessory
depending on the country)
# Model plate
Electrical specifications
RE 143, RE 143 PLUS
RE 163, RE 163 PLUS
Hydraulic specifications
RE 143, RE 143 PLUS
Specifications
Power supply: 230 V / 1~ / 50 Hz
1), 4)
220 V / 1~ / 50 Hz
2)
220 V / 1~ / 60 Hz
3)
Power output: 2.9 kW
1) 3)
2.2 kW
2)
2.8 kW
4)
Ampere rating: 12.6 A
1)
10 A
2)
13.2 A
3)
12.2 A
4)
Fuse, slow
(characteristic
"C" or "K"):
13 A
1) 2) 4)
15 A
3)
Protection
class: I
Type of
protection: IP X5
1)
230 V / 50 Hz version
2)
220 V / 50 Hz version
3)
220 V / 60 Hz version
4)
230 V / 50 Hz version GB
Power supply: 230 V / 1~ / 50 Hz
230 V - 240 V /
1~ / 50 Hz
5)
Power output: 3.3 kW
2.4 kW
5)
Ampere rating: 14.3 A
10 A
5)
Fuse, slow (char-
acteristic "C" or
"K"):
16 A
10 A
5)
Protection class: I
Type of
protection: IP X5
5)
230 V - 240 V / 50 Hz version
Working pressure: 14 MPa
1)
(140 bar)
12 MPa
2)
(120 bar)
12.2 MPa
3)
(122 bar)
12.8 MPa
4)
(128 bar)
Max. permissible
pressure:
15 MPa
(150 bar)
Max. water feed
pressure:
1MPa
(10 bar)
Max. water throughput: 610 l/h
1) 4)
520 l/h
2)
700 l/h
3)
