Stihl RE 163 User Manual

RE 143, RE 143 PLUS, RE 163, RE 163 PLUS
English
46
Holder for flat hose cassette
Depending on the country, the flat hose
cassette is included or is available as a
special accessory.
The holders for the flat hose cassette
are included in all versions and can be
installed as needed.
Installing the holder for versions with
included flat hose cassette
N Fasten the holder for the flat hose
cassette (1) to the holder on the
spray gun (3) with the included
screws (2)
N Unscrew screw (4)
N Fasten the catch hook for the flat
hose cassette (5) with the included
screw (6)
Installing the holder for versions without
included flat hose cassette
N Remove the screws (1) from the
spray gun holder
N Unscrew screw (2)
N Fasten the holder for the flat hose
cassette with the included
screws (3)
N Fasten the catch hook for the flat
hose cassette with the included
screw (4)
Height adjustable handle
N Press button (1) and pull handle (2)
upward as far as it will go
N Release button and pull/push on the
handle again until the telescopic
shafts engage
Carrying handle
The machine can be carried using the
transport handle.
1
3
1607BA036 KN
2
5
1607BA037 KN
4
6
1
1607BA026 KN
2
3
1607BA027 KN
4
Transporting the Unit
2
1607BA006 KN
1
1607BA049 KN
