0478 131 9940 B - EN
52
● Lift up the battery compartment
cover (1) and hold in the open position.
● Removing:
Remove the safety plug (2) from the
socket (3) and keep separately from
lawn mower.
Inserting:
Press the safety plug (2) as far as it will
go into the socket (3).
● Close the battery compartment
cover (1).
9.2 Eco mode switch
The eco mode switch that increases
battery running time is located in the
battery compartment. (Ö 10.2)
Switching on eco mode:
● Move switch to position I.
Switching off eco mode:
● Move switch to position 0.
9.3 Grass catcher box
Attaching:
● Open the discharge flap (1) and
hold it open.
● Attach the grass catcher box (2) to the
mountings (3) on the rear of machine by
means of the locating lugs.
● Close the discharge flap (1).
Detaching:
● Open the discharge flap (1) and hold it
open.
● Lift the grass catcher box (2) and
remove it rearwards.
● Close the discharge flap (1).
9.4 Adjusting the mono comfort
handlebar (RMA 443 C,
RMA 443 PC, RMA 443 TC,
RMA 448 PC, RMA 448 TC)
Folding down the handlebar:
Transport position (for cleaning, for
space-saving transport and for storage of
the machine):
● Hold upper handlebar (2) at its highest
point with one hand and lift (relieve
load) slightly.
● Press detent lever (1) downwards and
hold.
● Fold handlebar (2) down forwards,
ensuring that the electric cable is not
damaged.
Working position (to push machine):
● Fold handlebar (2) up rearwards and
ensure that the handlebar is fully
engaged.
Height adjustment:
The height of the mono comfort handlebar
can be adjusted to 2 levels:
● Hold upper handlebar (2) at its highest
point with one hand and lift (relieve
load) slightly.
● Press detent lever (1) downwards and
hold.
● Move handlebar (2) into the required
position.
● Release detent lever (1) and ensure
that the handlebar is again fully
engaged.
9.5 Folding down dual handlebar
(RMA 443)
Transport position (for cleaning, for
space-saving transport and for storage of
the machine):
● Loosen rotary handles (1) until they turn
freely.
● Fold down upper handlebar (2)
forwards.
Working position (to push machine):
● Fold up upper handlebar (2) rearwards
and hold with one hand.
● Tighten rotary handles (1). Make sure
that cable guide (3) is positioned
correctly.
9.6 Central cutting height
adjustment
Six different cutting heights can be
set.
Level 1 = 25 mm
13
16
Danger of pinching!
When operating the detent lever,
always hold the upper handlebar at
its highest point with one hand.
Never place your fingers between
the handlebar and bracket (above
and below the detent lever).
14
Danger of pinching!
The upper handlebar can be folded
down when the rotary handles are
released. Therefore hold the upper
handlebar with one hand at its
highest point when unscrewing the
rotary handles.
15
17
