Stihl RMA 443 User Manual

0478 131 9940 B - EN
60
Guaranteed sound power level:
92 dB(A)
RMA 448.0 PC:
Measured sound power level:
95,2 dB(A)
Guaranteed sound power level:
96 dB(A)
RMA 448.0 TC:
Measured sound power level:
95,2 dB(A)
Guaranteed sound power level:
96 dB(A)
Langkampfen,
2018-07-02 (YYYY-MM-DD)
STIHL Tirol GmbH
Head of Design
18.2 STIHL charger AL
This charger has been manufactured and
brought into circulation in compliance with
the following directives:
2014/30/EU, 2014/35/EU, 2011/65/EU
The full EC Declaration of Conformity is
available from ANDREAS STIHL AG & Co.
KG.
ANDREAS STIHL AG & Co. KG
Badstraße 115
D-71336 Waiblingen
Germany
19. Technical specifications
RMA 443.0, RMA 443.0 C,
RMA 443.0 PC, RMA 443.0 TC,
RMA 448.0 PC, RMA 448.0 TC
Type EC motor
Voltage 36 V
Protection class III
Type of protection IPX 1
Cutting device Cutter bars
Speed of cutting
device 3150 rpm
Speed of cutting
device in eco mode 2800 rpm
Cutter bar drive Permanent
Blade fastening
screw tightening
torque 60 - 65 Nm
Cutting height 25 - 75 mm
Grass catcher box 55 l
Wheel diameter
(front) 180 mm
Wheel diameter
(rear) 200 mm
RMA 443.0
Serial number 6338
Motor unit/battery MVP 600
Power input 600 W
Length 144 cm
Width 48 cm
Height 109 cm
Weight (without
battery) 20 kg
Cutting width 41 cm
Sound emissions:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
92 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
78 dB(A)
Uncertainty K
pA
2 dB(A)
Hand-arm vibrations:
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
1,80 m/sec
2
Uncertainty K
hw
0,90 m/sec
2
Measurement in accordance with
EN 20643
RMA 443.0 C
Serial number 6338
Motor unit/battery MVP 600
Power input 600 W
Length 138 cm
Width 49 cm
Height 108 cm
Weight (without
battery) 21 kg
Cutting width 41 cm
Sound emissions:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
92 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
78 dB(A)
Uncertainty K
pA
2 dB(A)
RMA 443.0

Stihl RMA 443 Specifications

General

Type	Walk behind lawn mower
Noise level	90 dB
Cutting width	410 mm
Grass catcher	Yes
Product color	Orange
Uncertainty K	1.1 m/s²
Rotational speed	3150 RPM
Maximum lawn area	- m²
Mulching function	-
Vibration emission	2.2 m/s²
Maximum cutting height	75 mm
Minimum cutting height	25 mm
Grass collecting volume	55 L
Number of height positions	5
International Protection (IP) code	IPX4
Battery type	Built-in battery
Power source	Battery

Weight and Dimensions

Weight	20000 g
