IMPREZA U.S.A. (E)
10-36
Clutch pedal (Manual transmission vehicles)
Check the clutch pedal free play and reserve distance according to the
maintenance schedule in the “Warranty and Maintenance Booklet”.
B Checking the clutch function
Check the clutch engagement and disengagement.
1. With the engine idling, check that there are no abnormal noises
when the clutch pedal is depressed, and that shifting into 1st or re-
verse feels smooth.
2. Start the vehicle by releasing the pedal slowly to check that the en-
gine and transmission smoothly couple without any sign of slippage.
B Checking the clutch pedal free play
OM-H0224
2.5L MT models
0.11 — 5.59 in
(3.0 — 15.0 mm)
2.2L MT models
0.40 — 0.79 in
(10.0 — 20.0 mm)
Lightly press the clutch pedal down with your finger until you feel re-
sistance, and check the free play.
If the free play is not within proper specification, contact your
SUBARU dealer.
To Next Page
