IMPREZA U.S.A. (E)
10-58
J Dome/Rear map reading lights (if equipped)
CAUTION
D While sitting in the vehicle, be sure to touch the metal frame of
the vehicle to allow all static electricity to be discharged prior to
replacing bulbs.
D Always use recommended replacement bulbs.
HBB038BAHBB037BA
1. Remove the dome light lens as follows:
Insert a small flat-tipped screwdriver into the center slot in the front edge
of the lens and lever the lens downward in such a way that it may be
bowed and disengaged from the mounting tabs.
2. To replace the dome light bulb (center bulb): remove the dome light
by pulling it out of its retainer clips, then insert a new bulb into the retain-
er clips.
3. To replace the map light bulbs: use a Phillips head screwdriver to re-
move the two mounting screws located on either side of the lamp assem-
bly. Pull the assembly downward out of the headliner. At this time, use
care not to touch the circuit board.
4. Remove the necessary bulb socket from the circuit board by grasping
it on the backside of the lamp assembly and twisting counterclockwise to
disengage.
5. Pull the bulb out of the socket. Install a new bulb by pushing it into the
socket.
To Next Page
