Sungrow EMS3000 User Manual

21
7
Appendix
7.1 Basic parameters
System
Controller EMS300
Workstation
Desktop computer
Ports
RS485 interface 7
DI / DO 16 / 4
Fiber port 4 * 100 Mbps
Ethernet port 20 * 10 / 100 Mbps
AI
2 * (4 - 20 mA), 2 * (0 - 10 Vdc)
CAN 1
PT100 / PT1000 2
Time Code Format B 1
Power supply
Power supply
100 - 240 Vac, 50 / 60 Hz, 1700W
Ambient parameters
Operating temperature
10℃~35℃
Operating humidity 10%~80% (non-condensing)
Elevation ≤ 4000 m
Protection class IP20
General parameters
Dimensions (W*H*D)
800mm x 2260mm x600mm
Scan the QR code below for the EMS300 WEB interface operation manual.
(Optional) Scan the QR code below for the Insight user manual.
