GSF1200AK6/SAK6 (’06-MODEL) 77
*1 Cut the tip of wire clamp after clamping. *2
Check the adhesive lead wire protection seat
when servicing.
*3
Don’t contact the ABS unit wire harness with
the ABS bracket.
Clamp
Engine mounting bracket
Turn signal (RH)
Turn signal (LH)
Wiring harness No.2
GSF1200AS
GSF1200A
Max. 10 mm (0.39 in)
*1
*2
*2
*2
Clamp
Side-stand switch
Neutral switch
Starter motor
Speed sensor
Wiring harness
Signal generator
Clamp
Wiring harness
Speed sensor
Neutral switch
ICES label (E-28 only)
10 mm (0.39 in)
Guide
ABS bracket
*3
Side-stand switch
14 N
.
m
(1.4 kgf-m, 10.0 lb-ft)
SAMPLE
