Suzuki AN650 Manual

1-6
LABELS
Read and follow all the labels on the
motorcycle. Make sure you under-
stand all of the labels. Do not remove
any labels from the motorcycle.
SERIAL NUMBER LOCATION
The frame and/or engine serial num-
bers are used to register the motorcy-
cle. They are also used to assist your
dealer when ordering parts or refer-
ring to special service information.
The frame number 1 is stamped on
the frame. The engine serial number
2 is stamped on the engine.
Please write down the numbers here
for your reference.
Frame No.:
Engine No.:

Suzuki AN650 Specifications

General

Manufacturer	Suzuki
Model	AN650
Displacement	638cc
Fuel System	Fuel injection
Maximum Torque	62 Nm (6.3 kgf-m) @ 6, 400 rpm
Fuel Capacity	15 L
Front Suspension	Telescopic fork
Rear Suspension	Swingarm, coil spring, oil damped
Front Brake	Disc, twin
Rear Brake	Disc
Front Tire	120/70
Rear Tire	160/60
Overall Length	2, 285 mm
Wheelbase	1, 585 mm
Ground Clearance	125 mm
Transmission	Continuously Variable Transmission (CVT)
