Suzuki AN650 Manual

2-32
TRUNK BOX LIGHT SWITCH
“ON” position
The trunk box light turns on.
“OFF” position
The trunk box light turns off.
STAND
This motorcycle is equipped with a
center stand and side stand.
CENTER STAND 1
To place the motorcycle on the center
stand, place your foot on the stand
extension and then rock the motorcy-
cle to the rear and upward with the
passenger hand rail with your right
hand, while steadying the handlebars
with your left hand.
NOTE: The transmission cannot shift
when the motorcycle is placed on the
center stand. Ride and move the
motorcycle to inspect shift operation.
SIDE STAND 2
An interlock system is provided to cut
off the ignition circuit when the side
stand is down.
The side stand/ignition interlock sys-
tem works as follows:
• If the side stand is down, the
engine can not be started.
• If the engine is running and the
side stand is put down, the engine
will stop running.
ON
OFF OFF

Suzuki AN650 Specifications

General

Manufacturer	Suzuki
Model	AN650
Displacement	638cc
Fuel System	Fuel injection
Maximum Torque	62 Nm (6.3 kgf-m) @ 6, 400 rpm
Fuel Capacity	15 L
Front Suspension	Telescopic fork
Rear Suspension	Swingarm, coil spring, oil damped
Front Brake	Disc, twin
Rear Brake	Disc
Front Tire	120/70
Rear Tire	160/60
Overall Length	2, 285 mm
Wheelbase	1, 585 mm
Ground Clearance	125 mm
Transmission	Continuously Variable Transmission (CVT)
