3-22
LEFT HANDLEBAR
Clutch Lever 1
The clutch lever is used for disen-
gaging the drive to the rear wheel
when starting the engine or shift-
ing transmission gears. Squeez-
ing the lever disengages the
clutch.
Dimmer Switch 2
“
” position
The headlight low beam and tail-
light turn on.
“
” position
Push the dimmer switch forward,
the headlight low beam, high
beam and taillight turn on. The
high beam indicator light also
turns on.
Headlight flasher switch
Press the switch to flash the
headlight.
MODE
P
A
S
S
SEL
NOTICE
Sticking tape or placing
objects in front of the headlight
can obstruct headlight heat
radiation. This can result in
headlight damage.
Do not stick tape on the head-
light or place objects in front of
the headlight.
NOTICE
Do not put objects in front of
the headlight or taillight when
they are on, and do not cover
with clothes when the motorcy-
cle is stopped.
This may cause melting of the
lens or damage to the object by
the heat from the lens.
To Next Page
