4-13
INSTRUMENT PANEL
66J21-03E
meter brightness becomes dimmest and
the other instrument panel lights are turned
off.
To brighten the instrument panel lights,
turn the knob (3) clockwise.
To cancel the automatic dimming feature
and maintain full brightness, turn the knob
(3) clockwise to position (5).
Tachometer
64J051
The tachometer indicates engine speed in
revolutions per minute.
Fuel Gauge
64J052
This gauge gives an approximate indica-
tion of the amount of fuel in the fuel tank.
“F” stands for full and “E” stands for empty.
If the indicator gets off the graduation of
“E” (not character “E”), refill the tank as
soon as possible.
NOTE:
The indicator moves a little depending on
road conditions (for example, slope or
curve) and driving conditions because of
fuel moving in the tank.
If the low fuel warning light (1) comes on,
fill the fuel tank immediately.
NOTE:
The activation point of the low fuel warning
light (1) varies depending on road condi-
CAUTION
Never drive with the engine speed
indicator in the red zone or severe
engine damage can result.
EXAMPLE
(1)
(2)
Speedometer/Odometer/Trip meter/Meter Illumination Control: 8
Tachometer: 8
Fuel Gauge: 8
