4-37

INSTRUMENT PANEL

66J21-03E

Type 1

AM/FM/XM CD PLAYER WITH CD CHANGER CONTROL (Built in CD Player)

66J099

(3)

(6)

(4)

(2)

(1)

(5)

Display

66J100

(1) CD insertion slot

(2) CD eject button

(3) Disc button (CD/AUX)

(4) Track up button/Fast forward button

(5) Track down button/Rewind button

(6) Repeat button (RPT)

(A) Mode indicator

(B) Track number

(D) Repeat indicator

(A)

(B)

(C)

(D)
