4-34

INSTRUMENT PANEL

66J21-03E

Listening to the Radio

66J216

(1)

(4)

(6)

(2)

(3)

(5)

(1)

(4)

(6)

(2)

(3)

(5)

Type 1 AM/FM/XM CD PLAYER WITH CD CHANGER CONTROL

Type 2 AM/FM/XM 6-CD PLAYER WITH CD CHANGER CONTROL

Display

66J097

(1) Band switch button (FM/AM)

(2) Seek up button

(3) Seek down button

(4) Manual tuning knob

(5) Preset buttons (1 to 6)

(6) Auto store button (AS)/

Scan button (SCAN)

(A) Band

(B) Preset channel number

(D) Frequency

(A)

(B)

(C)

(D)
