Suzuki GSX-S1000 User Manual

6-28
9. Mark the top dead center position
on the “cap type” filter wrench or
on the oil filter. Use an oil filter
wrench to tighten the filter 2 turns
or to specified torque.
Oil filter tightening torque:
20 N·m (2.0 kgf-m, 14.5 lbf-ft)
10. Replace the drain plug gasket with
a new one. Reinstall the drain plug
and gasket. Tighten the plug
securely with a torque wrench.
Pour 3200 ml (3.4/2.8 US/Imp. qt)
of new engine oil through the filler
hole and install the filler cap. Be
sure to always use the specified
engine oil described in the FUEL,
ENGINE OIL AND COOLANT
RECOMMENDATIONS section.
Drain plug tightening torque:
23 N·m (2.3 kgf-m, 16.5 lbf-ft)
NOTE: About 2800 ml (3.0/2.5 US/
lmp. qt) of oil will be required when
changing oil only.
Mark top dead center
Oil filter wrench
In the position at
which the filter
gasket first contacts
the mounting
surface.
Tighten the filter 2 turns or
to specified torque.
NOTICE
Engine damage may occur if you
use oil that does not meet
Suzuki’s specifications.
Be sure to use the oil specified in
the FUEL, ENGINE OIL AND
COOLANT RECOMMENDATIONS
section.

Suzuki GSX-S1000 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.2:1
Fuel System	Fuel injection
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc, twin
Rear Brakes	Disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	190/50ZR17M/C (73W), tubeless
Displacement	999 cm3
Overall Length	2115 mm
Overall Width	810 mm
Overall Height	1080 mm
Wheelbase	1460 mm
Ground Clearance	140 mm
Seat Height	810 mm
Curb Weight	214 kg
Fuel Tank Capacity	19 L (5.0 US gal)
