Suzuki GSX-S1000 User Manual

6-58
LICENSE PLATE LIGHT
To replace the license plate light bulb,
follow the procedure steps:
1. Remove the screws 1 and take
off the cover with the lens.
2. Pull off the bulb from the socket.
3. To replace the license plate light,
reverse the above steps.
FUSES
If something electrical on your motor-
cycle stops working, the first thing you
should check for is a blown fuse. The
electrical circuits on the motorcycle
are protected from overload by fuses
in the circuits.
If a blown fuse is found, then the elec-
trical problem must be inspected and
repaired before replacing the blown
fuse with a new fuse. Consult your
Suzuki dealer for the electrical system
check and repair.
WARNING
Replacing a fuse with a fuse that
has an incorrect amperage rating
or substitute, e.g. aluminum foil or
wire, may cause serious damage
to the electrical system and possi-
bly fire. Always replace a blown
fuse with a fuse of the same
amperage rating.
If the new fuse blows in a short
time, the electrical problem may
not be fixed. Have your motorcy-
cle inspected immediately by your
Suzuki dealer.

Suzuki GSX-S1000 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.2:1
Fuel System	Fuel injection
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc, twin
Rear Brakes	Disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	190/50ZR17M/C (73W), tubeless
Displacement	999 cm3
Overall Length	2115 mm
Overall Width	810 mm
Overall Height	1080 mm
Wheelbase	1460 mm
Ground Clearance	140 mm
Seat Height	810 mm
Curb Weight	214 kg
Fuel Tank Capacity	19 L (5.0 US gal)
