Suzuki GSX-S1000 User Manual

6-14
3. Lightly press the fairing toward the
inner side of the motorcycle, and
slide it backward to insert it into
the radiator hook 3.
NOTE: When the insertion of the radi-
ator hook 3 is completed, the inner
side of the fairing (Removal proce-
dure 6. Bolt Tightening Section) can
be aligned.
4. After completing the insertion of
the radiator hook 3, fix the fairing
in the reverse order of the removal
procedure.

Suzuki GSX-S1000 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.2:1
Fuel System	Fuel injection
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc, twin
Rear Brakes	Disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	190/50ZR17M/C (73W), tubeless
Displacement	999 cm3
Overall Length	2115 mm
Overall Width	810 mm
Overall Height	1080 mm
Wheelbase	1460 mm
Ground Clearance	140 mm
Seat Height	810 mm
Curb Weight	214 kg
Fuel Tank Capacity	19 L (5.0 US gal)
