6-46
3. Remove the axle nut 1.
4. Place an accessory service stand
or equivalent under the swingarm
to lift the rear wheel slightly off the
ground.
5. Loosen the right and left lock nuts
2. Loosen the right and left chain
adjusting bolts 3.
6. Draw out the axle shaft.
7. With the wheel moved forward,
remove the chain from the
sprocket.
8. Remove the rear brake caliper
assembly 4.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSX1250FA and is the answer not in the manual?

Suzuki GSX1250FA Specifications

General IconGeneral
Engine Type4-stroke, liquid-cooled, DOHC
Engine Displacement1255 cc
Bore x Stroke79.0 mm x 64.0 mm
Compression Ratio10.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
StarterElectric
Transmission6-speed constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Front BrakesDisc, twin
Rear BrakesDisc
Front Tire Size120/70ZR17M/C (58W), tubeless
Rear Tire Size180/55ZR17M/C (73W), tubeless
Overall Length2130 mm
Overall Width790 mm
Wheelbase1485 mm
Seat Height805 mm
Curb Weight257 kg
Fuel Tank Capacity19.0 L
