MJ70-410 Wing - Parts List
Item Part No. Description Qty
1 15000RM-WSCRPR-01 15000 WING SCRAPER BAR 2
2 15000RM2-WR01 410 WING ROLLER 2
3 725-BLD-FL 725 FIXED BLADE (Anti_Clk) 1
4 725-BLD-FR 725 FIXED BLADE (Clk) 1
5 8400RM-CV14 GUARD BASE MOUNT 2
6 8400RM-HG55 M20 ADJUSTER BLOCK 4
7 8400RM-HG65 M20 THREADED ADJUSTER 4
8 MJ70-270-PE01 PIVOT EYE 2
9 MJ70-460-GBR20 WING UNDERSIDE TROUGH 1
10 SW-270-LITR SWIFT LIGHT ASSY RH 1
11 SW-410-WG01 MJ70-410 WING 1
12 15000RM2-CV52 RUBBER FLAP 1
13 60CSD 60mm STAR DRIVE 2
14 8400RM-RPV01 ROLLER PIVOT 2
15 8400RM-RPV10 ROLLER PIVOT 2
16 DRV-RC-SWT410 MJ70-410 DRIVE 1
17 LS002 ANTI VIBRATION RUBBER 4
18 MJRC-23 113 PCD COUPLING 4mm PLT 2
19 S3035230012 6 SPLINE 'T' BOX RATIO 2.3 2
20 SW-410-CVR01 410 WING COVER 1
21 15000RM2-AF01 AERO-FOIL (MJ70-410) 1
22 15000RM2-CV53 WING RUBBER CLAMP 1
23 19000RM-AF02 AERO-FOIL (MJ70-550) 1
24 8400RM-HG03 HEIGHT INDICATOR 4
25 8400RM-HG04 HEIGHT GUIDE 4
26 SCRPR-SQ12-01 SCRAPER MOUNT 4
27 SW-240-DF02 REAR DEFLECTOR 1
28 SW-270-DF02 REAR DEFLECTOR 1
29 SW-410-DF01 RUBBER CLAMP 1
30 111044 DIA 26-30mm INSERT 4
31 12HEX109 1/2F HEX 10.9 12
32 12x112FSKS 1/2"x1 1/2" FINE SOCKET
HEAD 12.9
12
33 190760 GUARD (COVER 760/BASE
661)
1
34 3/4F 3/4" FINE NYLOC NUT 1
35 34x4FBZP 3/4"x4" FINE BOLT 1
36 5/8F 5/8" FINE NYLOC NUT 8
37 58x214FBZP 5/8"x2 1/4" FINE BOLT 8
38 851 GREASE NIPPLE M8x1.25
STR
8
39 CP176-181MG1 45mm INSERT 2
40 D281215 DISC SPRING 28x12x1.5 4
41 DSW34 DISC SPRING 34x16.3 x2 8
42 FWM12 M12 FLAT WASHER 65
43 FWM12L M12 FLAT WASHER (LARGE) 4
44 FWM16 M16 FLAT WASHER 8
45 FWM20 M20 FLAT WASHER 2
46 FWM8 M8 FLAT WASHER 22
47 G1106 BRASS TAP CONNECTOR 1
48 I-257 3/4x1/2 REDUCER BUSH 1
49 M12 M12 NYLOC NUT 51
50 M12x20SZP M12x20 SET BOLT 4
51 M12x25SKBH M12x25 SOCKET BUTTON
HEAD 10.9
8
52 M12x30SKBH M12x30 SOCKET BUTTON
HEAD 10.9
8
53 M12x30SZP M12x30 SET BOLT 15
54 M12x35SKBH M12x35 SOCKET BUTTON
HEAD 10.9
4
55 M12x40BZP M12x40 BOLT 4
56 M12x55SKBH M12x55 SOCKET BUTTON
HEAD 10.9
6
57 M12x60BZP M12x60 BOLT 8
58 M16x50SZP M16x50 SET BOLT 8
59 M20 M20 NYLOC NUT 1
60 M20x180BZP109 M20x180 BOLT (10.9) 1
61 M8 M8 NYLOC NUT 14
62 M8x100BZP M8x100 BOLT 4
63 M8x110BZP M8x110 BOLT 2
64 M8x16SKBH M8x16 SOCKET BUTTON
HEAD 10.9
8
65 M8x16SZP M8x16 SET BOLT 4
66 M8x20SKBH M8x20 SOCKET BUTTON
HEAD 10.9
2
67 NL12SP M12 SP NORDLOCK 16
68 NL16SP M16 SP NORDLOCK 8
www.major-equipment.com 39
