Model C706 Operating Procedures

080714

Step 13

Slide the large black o--ring and the two smaller black

o--rings into the grooves on the drive shaft. Thoroughly

lubricate the o--rings and shaft. DO NOT lubricate the

hex end of the shaft. (See Figure 29.)

Figure 29

Step 14

Install the hex end of the drive shaft into the drive hub

at the rear wall of the mix hopper. (See Figure 30.)

Figure 30

Note: For ease in installing the pump, position the ball

crank of the drive shaft in the 3 o’clock position.

Sanitizing

Step 1

Prepare an approved 100 PPM sanitizing solution

(examples: 2--1/2 gal. [9.5 liters] of Kay--5R or 2

gal. [7.6 liters] of Stera--SheenR). USE WARM WA-

TER AND FOLLOW THE MANUFACTURER’S

SPECIFICATIONS.

Step 2

Pour the sanitizing solution over all the parts in the

bottom of the mix hopper and allow it to flow into the

freezing cylinder.

Figure 31

Note: You have just sanitized the mix hopper and

parts; therefore, be sure your hands are clean and

sanitized before going on in these instructions.

Step 3

While the solution is flowing into the freezing cylinder,

take particular care to brush--clean the mix level

sensing probe on the front wall and the bottom of the

hopper, the mix hopper, the mix inlet hole, the air/mix

pump, the pump clip, the mix feed tube, and the locking

clip.
