Taylor C706 Original Operating Instructions

Section 10 Parts List
35
+ Available Separately
Model C706 Parts List
110118
DESCRIPTION PART
NUMBER
QTY. W ARR.
CLASS
REMARKS
ACCUMULATOR--CO PPER 2”DIA 10” 047062 1 103 RECEIVER REFRIGERANT BEARING--FRONT--SHOE 050348 1 000 USE X50350 KIT BEARING AND FRONT SHOES KIT A.--BEATER--FRONT SHOES X50350 1 000 BEARING--REAR SHELL *NICK.PLATE 031324 1 000
+GUIDE--D RIP SEAL 028992 1 000 +NUT--BRASS BEARING 028991 1 000 +O--RING--1/2OD X .070W 024278 1 000 +WASHER--BEARING LOCK 012864 1 000
BEATER A.--3.4QT--1 PIN--SUPPORT X46231 1 103
+BLADE--SCRAPER--PLASTIC 8--1/8L 046235 2 000 +CLIP--SCRAPER BLADE*7.00 INCH* 046236 2 103 +KIT A.--BEATER FRONT SHOES X50350 1 000
BELT--AX41 023876 2 000 208--230V 60HZ 1PH -- 208--230V 60HZ 3PH BLOCK--TERMINAL 2P--L1,L2 039422 1 103 208--230V 60HZ 1PH BLOCK--TERMINAL 3P--L1,L2,L3 039423 1 103 208--230V 60HZ 3PH BOARD--LOGIC--GEN 2.9--HOPR PMP X42002SERP 1 212 BOARD--POWER--GEN 1 & 2 X32326--SER 1 212 BRUSH--REAR BRG 1IN.DX2IN.LGX14 013071 1 000 BRUSH--DOUBLE ENDED--PUMP&FEED T 013072 1 000 BRUSH--DRAW VALVE 1”ODX2”X17”L 013073 1 000 BRUSH--END--DOOR--SPOUT--SS--HT 039719 1 000 BRUSH--MIX PUMP BODY--3”X7”WHITE 023316 1 000 BRUSH--SET LVB 050103 1 000 BRUSH--PUMP SPOUT *MC13* 054068 1 000 CABLE--RIBBON--PWR/RLY*C706* 60” 056295 1 103 COMPRESSOR L64A1 13BBCA 048259--27E 1 512 208--230V 60HZ 1PH -- BRISTOL K7026650 & UP
+CAPACITOR--ST AR T 189--227UF/330V 033044--1 1 103 +CAPACITOR--RUN 25UF/440V 037431 1 103 +RELAY--START--COMPRESSOR 062363 1 103 +GROMMET--COMPRESSOR MOUNT--AH 039923 4 000 +SLEEVE--MOUNTING--COMP.--AH 039924 4 000
COMPRESSOR AHA2490ZXD--AH556EF 047519--27F 1 512 208--230V 60HZ 1PH, TECUMSEH K7015617 & PRIOR
+CAPACITOR--RUN-- 35UF/440V 048132 1 103 +CAPACITOR--ST AR T--130--156UF/330V 036048 1 103
