How to Use the Manual Mode

There may be times when you want to disengage guitar

control of your harmonies and use a fixed key (e.g. E

Minor) instead. Using Manual mode does this. It could be

that you aren’t playing your guitar in a particular song or

that you’ve used fixed-key harmony in other TC-Helicon

products and found it works better and sounds unique

for some songs. In these cases, you can use the Manual

mode, also known as “Scale” in other TC-Helicon

products.

To use Manual mode, hold both footswitches then play

a chord on your guitar. If your song is in E minor for

example, play a simple Emin chord. As you strike the

chord, Harmony-G will automatically exit the key setting

mode so you can sing right away. Note that chords

containing extensions such as 7ths are not recognized.

If some of the harmony notes don’t sound correct to

you, you can choose from the three alternate scales by

re-entering Manual mode described above, and before

you play the chord, tapping the A/B footswitch to cycle

through the three alternate major or minor scales. A

number from 1 to 3 will show your selection in the

Preset display until you play the chord. If none of these

work, then it’s best to turn off the Manual button and

return to guitar-controlled harmony. If you wish to re-

use Manual mode and the key you’ve just set next time

you power up, you can hold the Preset button to store

it to the current preset number.

Advanced FX Style Select

Each effect style (Hall, Room etc.) has additional selections.

To browse additional Hall sounds, for example, first cycle

the FX button to the Hall style, then hold the FX button.

Tap the FX button to sample the options that are

numbered in the preset display. Once you’ve found one

you like, press and hold the FX button to exit. Hold the

Preset button to store if desired. Note that cycling through

the FX styles again with the FX button will return your edit

to the default style (#1) in each style bank.

For Advanced Users

Questions and Answers:

Need help?

Do you have a question about the TC-Helicon VoiceTone Harmony-G and is the answer not in the manual?

TC-Helicon VoiceTone Harmony-G Specifications

Analog Inputs

mic input impedance	1 kOhm
mic input sensitivity at 0dBFS	-44 dBu to +2 dBu
mic input sensitivity at 12dB headroom	-56 dBu to -10 dBu
guitar input impedance	1 MOhm
guitar input sensitivity	+15 dBu at 0dBFS
equivalent input noise	-126 dBu at max. mic amp gain, Rg = 150 Ohm

Analog Outputs

main output impedance	40 Ohm
main output level	+2 dBu at 0dBFS
guitar thru output impedance	270 Ohm

Input to Output Analog Audio Performance

dynamic range, mic at min gain	>108 dB, 20 Hz - 20 kHz A-weighted
dynamic range, mic at -18 dBu sensitivity	>104 dB, 20 Hz - 20 kHz
thd+ noise, mic at min gain	<-90 dB
frequency response at max gain	-1.5 dB at 40 Hz, +0/-0.3 dB (200 Hz to 20 kHz)
guitar in to thru dynamic range	>119 dB
tuning mute attenuation	>100 dB
