TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
No.
Button
Function
1
To turn on/off the air conditioner.
2
To increase temperature, or Timer setting hours.
3
To decrease temperature, or Timer setting hours.
4
MODE
To select the mode of operation (AUTO, COOL, DRY, FAN, HEAT).
5
ECO
To activate/deactivate the ECO function.
Long press to activate/deactivate the 8oC heating function (depending on
models).
6
TURBO
To activate/deactivate the TURBO function.
7
FAN
To select the fan speed of auto/mute/low/low-mid/mid/mid-high/high/turbo.
8
TIMER
To set the time for timer on/off.
9
SLEEP
To switch-on/off the function SLEEP.
10
DISPLAY
To switch-on/off the LED display.
11
To stop or start horizontal louver movement or set the desired up/down air
flow direction.
12
To stop or start horizontal louver movement or set the desired left/right air
flow direction.
13
I FEEL
To switch-on/off the I FEEL function.
14
MUTE
To switch-on/off the MUTE function.
Long press to activate/deactivate the GEN function (depending on models).
15
MODE + TIMER
To activate/deactivate the CHILD-LOCK function.
16
CLEAN
To activate/deactivate the SELF-CLEAN function (depending on models).
17
FAN + MUTE
or
GENTLE WIND
To activate/deactivate the GENTLE WIND function (depending on models)
(The function is not available for this series of products).
18
HEALTH
To activate/deactivate the HEALTH function (depending on models).
19
ANTI-MILDEW
To activate/deactivate the ANTI-MILDEW function.
The display and some functions of the remote control may vary according to the model.
The shape and position of buttons and indicators may vary according to the model, but their function
is the same.
The unit confirms the correct reception of each button with the beep.
