TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
4. Electronic Controller Introduction
4.1 Remote Controller
Remote control DISPLAY
Meaning of symbols on the liquid crystal display.
No.
Symbols
Meaning
1
Battery indicator
2
Auto Mode
3
Cooling Mode
4
Dry Mode
5
Fan only Mode
6
Heating Mode
7
ECO Mode
8
Timer
9
Temperature indicator
10
Fan speed:
Auto/ low/ low- mid/ mid/ mid- high/ high
11
Mute function
12
TURBO function
13
Up-down auto swing
14
Left-right auto swing
15
SLEEP function
16
Health function
17
I FEEL function
18
8oC heating function
19
Signal indicator
20
Gentle wind
21
Child-Lock
22
Display ON/OFF
23
GEN function
24
Self-Clean function
25
Anti-Mildew
The display and some functions of the remote controller may vary according to the model.
